| Pixel pitch:? | 2.5 |
| Brightness:? | 700 |
| Hz:? | 3840 |
| Cabinet material:? | Die-casting aluminum |
| Producing country: | Китай |
| Warranty period: | from 24 months |
"Indoor LED display K2.5 Plus" produced by "Absen"
K2.5 Plus 2.5 mm pixel pitch, recommended viewing distance - from 2 meters. Brightness - 700 candels. Cabinet weight 8.50 / 11.00 kg.
| K1.9 Plus | Current model K2.5 Plus | K3 Plus | ||||
|---|---|---|---|---|---|---|
| Pixel pitch? | 1.95 | 2.5 | 3.9 | |||
| Brightness? | 700 | 700 | 700 | |||
| Hz? | 3840 | 3840 | 1920 | |||
| Cabinet material? | Die-casting aluminum | Die-casting aluminum | Die-casting aluminum | |||
| LEDs | SMD1515 | SMD2121 | SMD2121 | |||
| Viewing angle horizontal? | 160 | 160 | 140 | |||
| Viewing angle vertical? | 160 | 160 | 140 | |||
| Type | outdoor-indoor | outdoor-indoor | outdoor-indoor | |||
| Module width | 250 | 250 | 250 | |||
| Module height | 250 | 250 | 250 | |||
| Gray scale | 14 | 12 | 14 | |||
| Pixel pitch front | 1.95 | 2.5 | 3.9 | |||
| Pixel pitch back | 1.95 | 2.5 | 3.9 | |||
| Cabinet width | 500 | 500 | 500 | 500 | 500 | 500 |
| Cabinet height | 750 | 1000 | 750 | 1000 | 750 | 1000 |
| Cabinet thickness | 63 | 63 | 63 | 63 | 63 | 63 |
| Cabinet weight | 8.5 | 11 | 8.5 | 11 | 8.5 | 11 |
| Average power | 60 | 80 | 56 | 75 | 34 | 45 |
| Maximum power | 180 | 240 | 169 | 225 | 101 | 135 |
| Cabinet service | Front/Back | Front/Back | Front/Back | Front/Back | Front/Back | Front/Back |
| Pixel pitch? | 2.5 | |
| Brightness? | 700 | |
| Hz? | 3840 | |
| Cabinet material? | Die-casting aluminum | |
| LEDs | SMD2121 | |
| Viewing angle horizontal? | 160 | |
| Viewing angle vertical? | 160 | |
| Type | outdoor-indoor | |
| Module width | 250 | |
| Module height | 250 | |
| Gray scale | 12 | |
| Pixel pitch front | 2.5 | |
| Pixel pitch back | 2.5 | |
| Cabinet width | 500 | 500 |
| Cabinet height | 750 | 1000 |
| Cabinet thickness | 63 | 63 |
| Cabinet weight | 8.5 | 11 |
| Average power | 56 | 75 |
| Maximum power | 169 | 225 |
| Cabinet service | Front/Back | Front/Back |
