Current model AX1.2 Pro | AX1.2 | AX1.5 | AX1.5 Pro | AX1.9 | |
---|---|---|---|---|---|
Pixel pitch? | 1.27 | 1.27 | 1.59 | 1.59 | 1.91 |
Brightness? | 1500 | 600 | 800 | 1000 | 1200 |
Hz? | 7680 | 3840 | 3840 | 3840 | 3840 |
Cabinet material? | Die-casting aluminum | Die-casting aluminum | Die-casting aluminum | Die-casting aluminum | Die-casting aluminum |
Viewing angle horizontal? | 160 | 160 | 160 | 160 | 140 |
Viewing angle vertical? | 160 | 140 | 140 | 140 | 140 |
Type | outdoor-indoor | outdoor-indoor | outdoor-indoor | outdoor-indoor | outdoor-indoor |
Module width | 152.5 | 152.5 | 152.5 | 152.5 | 152.5 |
Module height | 343 | 343 | 343 | 343 | 343 |
Gray scale | 15 | 14 | 14 | 14 | 14 |
Pixel pitch front | 1.27 | 1.2707 | 1.5883 | 1.5883 | 1.905 |
Pixel pitch back | 1.27 | 1.2707 | 1.5883 | 1.5883 | 1.905 |
Cabinet width | 610 | 610 | 610 | 610 | 610 |
Cabinet height | 343 | 343 | 343 | 343 | 343 |
Cabinet thickness | 80 | 67 | 67 | 80 | 67 |
Cabinet weight | 9.2 | 7.8 | 7.8 | 9.2 | 7.8 |
Average power | 53 | 41 | 60 | 56 | 46 |
Maximum power | 160 | 124 | 180 | 169 | 139 |
Cabinet service | Front/Back | Front | Front | Front/Back | Front |
Pixel pitch? | 1.27 |
Brightness? | 1500 |
Hz? | 7680 |
Cabinet material? | Die-casting aluminum |
Viewing angle horizontal? | 160 |
Viewing angle vertical? | 160 |
Type | outdoor-indoor |
Module width | 152.5 |
Module height | 343 |
Gray scale | 15 |
Pixel pitch front | 1.27 |
Pixel pitch back | 1.27 |
Cabinet width | 610 |
Cabinet height | 343 |
Cabinet thickness | 80 |
Cabinet weight | 9.2 |
Average power | 53 |
Maximum power | 160 |
Cabinet service | Front/Back |
