The appearance of the cabinet is variable, and may differ from that presented on the site.

Indoor LED display Unilumin UpadIII2

Pixel pitch:?	2.6
Brightness:?	1000
Hz:?	3840
Cabinet material:?	Die-casting aluminum
Producing country:	Китай
Warranty period:	from 24 months

Indoor

Order calculation

"Indoor LED display UpadIII2" produced by "Unilumin"

UpadIII2 2.6 mm pixel pitch, recommended viewing distance - from 2 meters. Brightness - 1000 candels, which allows only indoor usage of this LED screen. Cabinet weight 9.00 kg.

	Current model UpadIII2	UpadIII3	UpadIII H03		UpadIII H04		UpadIII H05		UpadIII H07
Pixel pitch?	2.6	3.9	3.9		4.8		5.9		7.8
Brightness?	1000	1000	5000		5000		5000		5000
Hz?	3840	3840	3840		3840		3840		3840
Cabinet material?	Die-casting aluminum	Die-casting aluminum	Die-casting magnesium		Die-casting magnesium		Die-casting magnesium		Die-casting magnesium
LEDs	SMD	SMD	SMD		SMD		SMD		SMD
Viewing angle horizontal?	140	140	140		140		140		140
Viewing angle vertical?	120	120	120		120		120		120
Type	indoor	indoor	outdoor		outdoor		outdoor		outdoor
Module width	250	250	250		250		250		250
Module height	250	250	500		500		500		500
Pixel pitch front	2.6	3.9	3.9		4.8		5.9		7.8
Pixel pitch back	2.6	3.9	3.9		4.8		5.9		7.8
Cabinet width	500	500	500	500	500	500	500	500	500	500
Cabinet height	500	500	500	1000	500	1000	500	1000	500	1000
Cabinet thickness	92	92	74	74	74	74	74	74	74	74
Cabinet weight	9	9	6.3	11	6.3	11	6.3	11	6.3	11
Average power	40	40	60	110	60	110	60	110	60	110
Maximum power	120	120	180	350	180	350	180	350	180	350
Cabinet service	Back	Back	Back	Back	Back	Back	Back	Back	Back	Back

Pixel pitch?	2.6
Brightness?	1000
Hz?	3840
Cabinet material?	Die-casting aluminum
LEDs	SMD
Viewing angle horizontal?	140
Viewing angle vertical?	120
Type	indoor
Module width	250
Module height	250
Pixel pitch front	2.6
Pixel pitch back	2.6
Cabinet width	500
Cabinet height	500
Cabinet thickness	92
Cabinet weight	9
Average power	40
Maximum power	120
Cabinet service	Back
