The appearance of the cabinet is variable, and may differ from that presented on the site.

Indoor LED display Dicolor MS-100 Outdoor

Pixel pitch:?	10.41
Brightness:?	6500
Hz:?	3840
Cabinet material:?	Die-casting aluminum
Producing country:	Китай
Warranty period:	from 24 months

Indoor

Order calculation

"Indoor LED display MS-100 Outdoor" produced by "Dicolor"

MS-100 Outdoor 10.41 mm pixel pitch, recommended viewing distance - from 8 meters. Brightness - 6500 candels, which provides great visibility for this LED screen even in sunny weather. Cabinet weight 29.00 kg.

	MS-191	MS-261	MS-291	MS-391	MS-480 Outdoor	MS-780 Outdoor	Current model MS-100 Outdoor
Pixel pitch?	1.95	2.6	2.97	3.91	4.81	7.81	10.41
Brightness?	800	800	800	800	5000	6000	6500
Hz?	3840	3840	3840	1920	1920	1920	3840
Cabinet material?	Aluminum				Die-casting aluminum	Die-casting aluminum	Die-casting aluminum
LEDs	SMD
Pixel configuration?	1R1G1B
Viewing angle horizontal?	140
Viewing angle vertical?	140
IP rate front?	40
IP rate back?	21
Type	indoor	indoor	indoor	indoor	outdoor	outdoor	outdoor
Module width	250
Module height	250
Gray scale	14	14	14	14	14	14	14
Pixel pitch front	1.9531	2.604	2.97	3.91	4.81	7.81	10.41
Pixel pitch back	1.9531	2.604	2.97	3.91	4.81	7.81	10.41
Cabinet width	500	500	500	500	1000	1000	1000
Cabinet height	500	500	500	500	1000	1000	1000
Cabinet thickness	62	62	62	62	100	100	100
Cabinet weight	6	6	6	6	31	31	29
Average power	42	45	45	33	274	275	300
Maximum power	125	136	136	100	820	824	900
Cabinet installation	Rental/FIX
Cabinet service	Front	Front	Front	Front	Front	Front	Front

Pixel pitch?	10.41
Brightness?	6500
Hz?	3840
Cabinet material?	Die-casting aluminum
Type	outdoor
Gray scale	14
Pixel pitch front	10.41
Pixel pitch back	10.41
Cabinet width	1000
Cabinet height	1000
Cabinet thickness	100
Cabinet weight	29
Average power	300
Maximum power	900
Cabinet service	Front
