| Pixel pitch:? | 1.25 |
| Brightness:? | 600 |
| Hz:? | 3000 |
| Cabinet material:? | Die-casting aluminum |
| Producing country: | Китай |
| Warranty period: | from 24 months |
"Indoor LED display R1.2" produced by "Ledman"
R1.2 1.25 mm pixel pitch, recommended viewing distance - from 1 meters. Brightness - 600 candels. Cabinet weight 7.20 kg.
| R0.9 | Current model R1.2 | R1.5 COB | |
|---|---|---|---|
| Pixel pitch? | 0.93 | 1.25 | 1.56 |
| Brightness? | 450 | 600 | 600 |
| Hz? | 3000 | 3000 | 3000 |
| Cabinet material? | Die-casting aluminum | Die-casting aluminum | Die-casting aluminum |
| LEDs | COB 3in1 | COB RGB LED | |
| Viewing angle horizontal? | 170 | 160 | |
| Viewing angle vertical? | 160 | 170 | |
| IP rate front? | |||
| IP rate back? | |||
| Type | outdoor-indoor | outdoor-indoor | indoor |
| Module width | 300 | 330 | |
| Module height | 337.5 | 337.5 | |
| Gray scale | 13 | 13 | 13 |
| Pixel pitch front | 0.93 | 1.25 | 1.56 |
| Pixel pitch back | 0.93 | 1.25 | 1.56 |
| Cabinet width | 600 | 600 | 600 |
| Cabinet height | 337.5 | 337.5 | 337.5 |
| Cabinet thickness | 60 | 60 | 60 |
| Cabinet weight | 6.5 | 7.2 | 7.2 |
| Average power | 30 | 30 | 30 |
| Maximum power | 91 | 91 | 91 |
| Cabinet installation | Fix | Rental/FIX | |
| Cabinet service | Front | Front | Front |
